INZTAAFRAME
Great ceilings start from within.
A ceiling is only as good as the frame holding it up. HomeSure RockEx InztaaFrame Integrated Suspended Ceiling System delivers a high-performance metal frame work for modern gypsum board applications. It is the hidden engineering that makes suspended ceilings possible, with a complete ecosystem of sections, channels, angles and clips.
Precision-manufactured from hot-dip galvanized, cold-formed steel, each component is engineered to meet exact standards, ensuring exceptional structural stability, precise level consistency and long-term corrosion resistance for seamless, high-end interior finishes.
Whether it’s for a compact apartment, an individual home or a larger areas, from primary framework to perimeter edges, HomeSure RockEx InztaaFrame is designed for fast, hassle-free installation, accurate alignment and lasting rigidity, with zero compromise on finish.
Products
Ceiling Section
Intermediate Channel
Perimeter Channel
Ceiling Angle
5 Star Advantage
- Fast Installation – Lightweight sections for easy handling, cutting, and installation.
- Precision Engineered – High-precision manufacturing ensures consistent dimensions, accurate alignment, and hassle-free installation.
- Reliable structural stability – Optimized profile design and gauge thickness deliver exceptional strength to support boards, fixtures, and services.
- Superior Corrosion Resistance – 120 GSM hot-dip galvanized steel (IS 277:2018) enhances durability and corrosion resistance in interior applications.
- Anti-Slip Technology – Precision-knurled surface improves screw hold, prevents slippage, and keeps boards firmly in place.
Technical Specification
Recommended Grid Arrangement
Technical Specification
| Parameters | Ceiling Section | Heavy Intermediate Channel | Perimeter Section | Ceiling Angle |
| Purpose | Main supporting section to fix gypsum plasterboard | Primary section to support the ceiling section; hang from soffit via ceiling angle & soffit cleat | Fixed at wall periphery to receive ends of ceiling & intermediate sections | Hanger to suspend intermediate channels from RCC slab/soffit |
| Section Configuration | Top × Flange × Web | Web × Flange | Long Leg × Web × Short Leg | Long Leg × Short Leg |
| Dimensions (in mm) | 76 × 20 × 42 | 45 × 15 × 15 | 30 × 22 × 20 | 25 × 10 |
| Base Metal Thickness (in mm) | 0.40 ± 0.05 | 0.60 ± 0.05 | 0.40 ± 0.05 | 0.40 ± 0.05 |
| Standard Length (in mm) | 3660 ± 3 | 3660 ± 5.0 | 3660 ± 5.0 | 3660 ± 5.0 |
| Galvanisation (in gsm) (As per IS 277:2018) | 120 | 120 | 120 | 120 |
| Minimum Yield Strength (in MPa) | 240 | 240 | 240 | 240 |
| Parameter | Specification |
| Material | Hot Dip Galvanized Cold Formed Steel |
| Galvanisation | 120 gsm as per IS 277:2018 |
| Minimum Yield Strength | 240 MPa |
| Dimensional Tolerance | ± 0.50 mm |
| Applicable Standards | IS 277:2018, IS 513 (Part 1):2016 |
Recommended Grid Arrangement
| Component | Recommended Spacing |
| Hanger Spacing | Maximum 1200 mm |
| Intermediate Channel Spacing | 900 mm to 1200 mm |
| Ceiling Section Spacing (Subject to Loading) | 457 mm |
